Tracking Equipment DDTS DucTrak
/
/
/
/
Tracking Equipment DDTS DucTrak


DFT: Dual Frequency (1.5 / 33 kHz) For use with the Mark V System
DFT: Dual Frequency (1.5 / 33 kHz) For use with the Mark V System
Length x Diameter Depth Range Battery Type Temp. Rating Weight
15 in. x 1.25 in.
38 cm x 3.18 cm
40 ft
12.2 m
2 C-cell alkaline
20 hours awake
200 hours sleep
220°F
104°C
1.4 lb
635 g



DS: Short Range (Blue) Mark III/IV compatible
DS: Short Range (Blue) Mark III/IV compatible
Length x Diameter Depth Range Battery Type Temp. Rating Weight
8 in. x 1.00 in.
20 cm x 2.5 cm
15 ft
4.6 m
1AA-cell alkaline
12 hours awake
50 hours sleep
180°F
82°C
8.4 oz
240 g



DT: Standard Range (Yellow) Mark III/IV/V compatible
DT: Standard Range (Yellow) Mark III/IV/V compatible
Length x Diameter Depth Range Battery Type Temp. Rating Weight
15 in. x 1.25 in.
38 cm x 3.18 cm
40 ft
12.2 m
2 C-cell alkaline
30 hours awake
200 hours sleep
220°F
104°C
1.4 lb
635 g



DX: Long Range (Red) Mark III/IV/V compatible
DX: Long Range (Red) Mark III/IV/V compatible
Length x Diameter Depth Range Battery Type Temp. Rating Weight
15 in. x 1.25 in.
38 cm x 3.18 cm
70 ft
21.3 m
2 C-cell alkaline
20 hours awake
200 hours sleep
220°F
104°C
1.4 lb
635 g



D4X: DX with Extended Life (Red) Mark III/IV/V compatible
DS: Short Range (Blue) Mark III/IV compatible
Length x Diameter Depth Range Battery Type Temp. Rating Weight
19 in. x 1.25 in.
48 cm x 3.18 cm
70 ft
21.3 m
4 C-cell alkaline
40 hours awake
400 hours sleep
220°F
104°C
1.85 lb
840 g



DXP: Long Range with 0.1% Pitch (Magenta) Mark III/IV/V compatible
Pitch range -10% to 10%. For level drilling use only
DXP: Long Range with 0.1% Pitch (Magenta) Mark III/IV/V compatible
Length x Diameter Depth Range Battery Type Temp. Rating Weight
15 in. x 1.25 in.
38 cm x 3.18 cm
70 ft
21.3 m
2 C-cell alkaline
20 hours awake
200 hours sleep
220°F
104°C
1.4 lb
635 g



D4XP: D4X with 0.1% Pitch (Magenta) Mark III/IV/V compatible
Pitch range -10% to 10%. For level drilling use only
D4XP: D4X with 0.1% Pitch (Magenta) Mark III/IV/V compatible
Length x Diameter Depth Range Battery Type Temp. Rating Weight
19 in. x 1.25 in.
48 cm x 3.18 cm
70 ft
21.3 m
4 C-cell alkaline
40 hours awake
400 hours sleep
220°F
104°C
1.85 lb
840 g



DCX: Cable Transmitter (Green) Mark III/IV/V compatible
DCX: Cable Transmitter (Green) Mark III/IV/V compatible
Length x Diameter Depth Range Battery Type Temp. Rating Weight
15 in. x 1.25 in.
38 cm x 3.18 cm
15 in. x 1.25 in.
38 cm x 3.18 cm
12V to 28V DC
cable power
180°F
82°C
1.2 lb
545 g



DCP: DCX with 0.1% Pitch (Magenta) Mark III/IV/V compatible
DCP: DCX with 0.1% Pitch (Magenta) Mark III/IV/V compatible
Length x Diameter Depth Range Battery Type Temp. Rating Weight
15 in. x 1.25 in.
38 cm x 3.18 cm
15 in. x 1.25 in.
38 cm x 3.18 cm
12V to 28V DC
cable power
180°F
82°C
1.2 lb
545 g



DucTrak™ Series Transmitters

DucTrak™ is designed to track existing non-metal duct to depths greater than 100 feet. It does not send out a roll / pitch signal and is not intended for horizontal directional drilling operations. The DDT/DDTS models are designed for use with the Mark series locators

DDT DucTrak™ Extended Range Transmitter – Mark III/IV/V compatible
DDT DucTrak™ Extended Range Transmitter - Mark III/IV/V compatible
Length x Diameter Depth Range Battery Type Temp. Rating Weight
12 in. x 0.875 in.
30.5 cm x 2.2 cm
100 ft
30.5 m
Type DL 123 3V lithium
8–12 hour life (approx.)
22°F to 122°F
-5.6°C to 50°C
8.4 oz
240 g



DDTS DucTrak™ Transmitter – Mark III/IV/V compatible
DDTS DucTrak™ Transmitter - Mark III/IV/V compatible
Length x Diameter Depth Range Battery Type Temp. Rating Weight
6 in. x 0.875 in.
15.2 cm x 2.2 cm
50 ft
15.2 m
Type DL 123 3V lithium
8–12 hour life (approx.)
22°F to 122°F
-5.6°C to 50°C
4.5 oz
127 g
